High Strength HTD5M Rubber Timing Belt Synchronous Belt Arc Tooth
Arc Tooth Timing Belt is a specially designed synchronous transmission belt with an arc-shaped tooth profile (HTD, RPP/HPPD, STPD/STS). It is specially designed for high torque and high-speed applications and is an alternative to the traditional trapezoidal tooth profile. The upgrade can provide reliable power transmission and motion control for the transmission system.
Technical parameters:
| Tooth Profile | Type | Pitch(mm) | Tooth Height(mm) | Belt Thickness(mm) |
| HTD | 2M | 2.00 | 0.75 | 1.36 |
| 3M | 3.00 | 1.17 | 2.4 |
| 5M | 5.00 | 2.06 | 3.8 |
| 8M | 8.00 | 3.36 | 6.00 |
| 14M | 14.00 | 6.02 | 10.00 |
| 20M | 20.00 | 8.4 | 13.20 |
| STPD/STS | S2M | 2.00 | 0.76 | 1.36 |
| S3M | 3.00 | 1.14 | 1.9 |
| S4.5M | 4.50 | 1.71 | 2.81 |
| S5M | 5.00 | 1.91 | 3.4 |
| S8M | 8.00 | 3.05 | 5.3 |
| S14M | 14.00 | 5.3 | 10.2 |
| RPP/HPPD | P2M | 2.00 | 0.76 | 1.36 |
| P3M | 3.00 | 1.15 | 1.9 |
| P5M | 5.00 | 1.95 | 3.5 |
| P8M | 8.00 | 3.2 | 5.5 |
| P14M | 14.00 | 6.00 | 10 |
Advantage:
1. High transmission stability: The arc tooth timing belt has a reasonable tooth groove design, which makes the synchronous pulley and the belt body more closely meshed, which can reduce the tooth skipping phenomenon in the transmission and the energy loss during the transmission process. This ensures the stability of the transmission.
2. Low noise: The tooth design of the arc tooth timing belt reduces the impact and vibration during the transmission process, thereby reducing the generation of noise and making the transmission more stable. This also enables it to withstand greater loads.
3. Long service life: The arc tooth timing belt is made of high-strength polyurethane or rubber material, which has good wear resistance and corrosion resistance and can maintain a long service life.
Photo Reference:
